ICON 2005-07 Ford F250/F350, 7" Lift, Stage 3 Suspension System at Sexton Offroad in Salt Lake City & Park City, Utah

ICON’s 7” Suspension System for the 2005-2007 Ford Super Duty’s offer unparalleled performance and ride quality while giving the vehicle clearance for 38” tall tires. This system comes complete with ICON 2.5 Aluminum Series Shocks, Dual-Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, and ICON's Fabricated 6" Blocks and U-bolts. All of these components (excluding shocks) are covered by ICON’s Limited Lifetime Warranty.

Features | Specification:

• 75% increase in wheel travel
• Less body roll than stock truck
• 7" more travel from ride height to front bump stops
• State of the art dual-rate coil spring
• Lifetime guarantee that coil springs won’t sag
• Clears 38" Tall Tires
• No change in towing capacity
• No driveshaft modifications needed
• 100% Bolt-on system - No drilling, cutting, or welding necessary

Note(s):

• OEM Wheels & Tires Fitment: Yes
• Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
• Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
• APPLICATION NOTE #6: Springs Are Rated For Diesel Engines Only
• APPLICATION NOTE #21: Not Applicable On Vehicles Equipped With A Manual Transmission
• APPLICATION NOTE #28: Pinch Weld On ‘05-’10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
• APPLICATION NOTE #29: 7” Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams. Caster Can Be Adjusted By The Lower Link Arms
• APPLICATION NOTE #55: Shocks Are Fully Serviceable. Coilover Heights Indicated Are For A Stock Equipped Vehicle
• APPLICATION NOTE #57: Retains Factory Block For Truck To Sit Level With Front Of Truck
• Ships in multiple boxes

Upgrade your 4x4 with quality parts and accessories from Sexton Offroad. Visit us for installation at our Salt Lake City or Park City, Utah locations. Plus, enjoy free shipping on thousands of products nationwide!

This Item Fits:

• Ford F-250 Super Duty 2005 - 2007 4WD
• Ford F-350 Super Duty 2005 - 2007 4WD
