ICON 2005-2016 Ford F-250/F-350 Super Duty 4WD Diesel, 2.5" Lift, Stage 6 Suspension System at Sexton Offroad in Salt Lake City & Park City, Utah

The ICON 2.5” suspension system is a great way to level your 4WD 2005-2016 Ford F250/350 Super Duty while improving ride quality and performance. This Stage 5 system is great for towing, rough construction site terrains, and country dirt roads all while keeping a smooth highway feel. Also included in this stage is ICON's CDC Valve front to back for those desiring an easy way to tune the ride externally with 10 settings from soft to hard. ICON's Stage 5 System is comprised of dual rate coil springs, alignment cams for adding caster, adjustable track bar w/ bearing, dual steering stabilizer kit with ICON 2.0 Aluminum Series stabilizers, and ICON 2.5 Aluminum Series remote reservoir shocks front and rear w/ CDCV. ICON 2.5" reservoir shocks ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. With the endless hours ICON has spent testing and tuning our suspension components and shocks as a complete package, you can rest assured you have the best suspension solution on the market.

This Stage 6 system sees the inclusion of the ICON Vehicle Dynamics Ford Super Duty Radius Arm System that feature a sealed pivot bushing that minimizes road feedback and ensures a long life and quiet operation. Their on vehicle caster adjustment allows for proper caster while eliminating the need for caster bushings or drop brackets. Additionally, their fabricated, fully boxed design ensures strength and utilizes a profile optimized for tire clearance at full steering lock, making a 37” tall tire clear without coming in contact with the radius arm.

Features | Specification:

• ICON engineered dual rate coil springs with match tuned performance shocks
• No drive shaft modifications required
• Corrosion resistant anodized aluminum shock bodies with 7/8" shafts (2.5 Aluminum Series shocks)
• 100% Bolt-on system -no cutting or welding necessary for install
• Remote reservoir with easy to adjust compression tune-ability
• Application Specific Alignment Cams ensure proper Caster alignment
• Increased wheel travel and ride quality over stock with no change in towing capacity
• Adjustable trackbar for optimum front axle centering and minimizing deflection
• Dual steering stabilizer kit for smooth wheel control while driving
• Less body-roll than stock
• Lifetime guarantee that coil springs won’t sag
• Fabricated radius arms offer on vehicle caster adjustment, increased strength, and improved tire clearance at steering lock

Note(s):

• OEM Wheels & Tires Fitment: Yes
• Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
• Recommended Aftermarket Tires: 35" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
• APPLICATION NOTE #6: Springs Are Rated For Diesel Engines Only
• APPLICATION NOTE #55: Shocks Are Fully Serviceable. Coilover Heights Indicated Are For A Stock Equipped Vehicle
• APPLICATION NOTE #94: Not Compatible With F-350 Equipped with Wide Track Front Axle
• Compatible with 4WD models only
• 2005-2016 F-250s require 4” rear blocks with 15” U-bolt kit to sit level with 2.5” lifted front. ICON block kit part # 194275 and U-bolt kit part # 37003 (2005-2010 models) or part # 67003 (2011-2016 models) are recommended.
• Not compatible with F-350 Cab & Chassis models
• ICON track bar bracket part # 64039 is also recommended to correct bump steer geometry on 2008-2016 models
• Included rear shocks are compatible with 0-3" of rear lift over stock

Upgrade your 4x4 with quality parts and accessories from Sexton Offroad. Visit us for installation at our Salt Lake City or Park City, Utah locations. Plus, enjoy free shipping on thousands of products nationwide!

This Item Fits:

• Ford F-250 Super Duty 2005 - 2007 4WD
• Ford F-250 Super Duty 2008 - 2010 4WD
• Ford F-250 Super Duty 2011 - 2016 4WD
• Ford F-350 Super Duty 2005 - 2007 Standard Cab Pickup 4WD
• Ford F-350 Super Duty 2005 - 2007 Extended Cab Pickup 4WD
• Ford F-350 Super Duty 2005 - 2007 Crew Cab Pickup 4WD
• Ford F-350 Super Duty 2008 - 2016 Standard Cab Pickup 4WD
• Ford F-350 Super Duty 2008 - 2016 Extended Cab Pickup 4WD
• Ford F-350 Super Duty 2008 - 2016 Crew Cab Pickup 4WD
• Ford F-350 Super Duty 2008 - 2010 Standard Cab Pickup 4WD
• Ford F-350 Super Duty 2008 - 2010 Extended Cab Pickup 4WD
• Ford F-350 Super Duty 2008 - 2010 Crew Cab Pickup 4WD
• Ford F-350 Super Duty 2011 - 2014 Standard Cab Pickup 4WD
• Ford F-350 Super Duty 2011 - 2014 Extended Cab Pickup 4WD
• Ford F-350 Super Duty 2011 - 2014 Crew Cab Pickup 4WD
• Ford F-350 Super Duty 2015 - 2016 Standard Cab Pickup 4WD
• Ford F-350 Super Duty 2015 - 2016 Extended Cab Pickup 4WD
• Ford F-350 Super Duty 2015 - 2016 Crew Cab Pickup 4WD
