ICON 2019-Up Ram 1500, 0-3” Lift, Rear, 2.5 VS Piggy/CDCV Shocks, Pair at Sexton Offroad in Salt Lake City & Park City, Utah

ICON’s 2.5 Aluminum Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Featuring one-piece impact extruded aluminum cylinders, these 2.5 Aluminum Series shocks offer lighter weight, improved corrosion resistance, and a more uniform finish than traditional plated steel cylinders. Like all ICON'S Shock Absorbers, 2.5 Aluminum Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications, ICON'S unique use of a 6061 billet aluminum manifold a few inches below thetop cap of the shock creates an internal Bump Zone that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. The ICON CDC Valve is an externally adjustable valve that restricts oil flow into the reservoir which creates 10 levels of compression damping force ranges.

Features | Specification:

• ICON's CDC Valve technology allows for 10 levels of high-resolution compression adjustability with the turn of a knob
• One-piece impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
• 100% Rebuildable
• 100% Revalveable
• ICON’s internal “Bump Zone" increases damping by 20% to provide more control as the shock approaches full compression
• Piggyback reservoir design improves heat dissipation to reduce shock fade during prolonged use
• Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
• Nitrogen charged monotube design with piggyback reservoir
• Double-sealed Schrader caps reduce risk of damage
• One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
• 7/8" diameter induction hardened, chrome plated shock shaft
• PTFE lined spherical bearings and application specific mounting hardware
• 6061 aircraft grade aluminum CNC machined components

Note(s):

• Not compatible with 2019-2022 Ram 1500 Classic models
• Not compatible with 2021-Up Ram 1500 TRX trims.

Upgrade your 4x4 with quality parts and accessories from Sexton Offroad. Visit us for installation at our Salt Lake City or Park City, Utah locations. Plus, enjoy free shipping on thousands of products nationwide!

This Item Fits:

• Ram 1500 2019 - 2020
• Ram 1500 Limited 2021
• Ram 1500 Sport 2021
• Ram 1500 SLT 2021
• Ram 1500 ST 2021
• Ram 1500 Laramie 2021
• Ram 1500 Hemi Sport 2021
• Ram 1500 Rebel 2021
• Ram 1500 Big Horn 2021
• Ram 1500 Lone Star 2021
• Ram 1500 Tradesman 2021
• Ram 1500 Laramie Longhorn 2021
• Ram 1500 HFE 2021
• Ram 1500 Longhorn 2021
• Ram 1500 Laramie Sport 2021
• Ram 1500 Limited Longhorn 2021
• Ram 1500 Limited 2022
• Ram 1500 Sport 2022
• Ram 1500 Laramie 2022
• Ram 1500 Rebel 2022
• Ram 1500 Big Horn 2022
• Ram 1500 Lone Star 2022
• Ram 1500 Tradesman 2022
• Ram 1500 HFE 2022
• Ram 1500 Limited Longhorn 2022
