ICON 2019-Up Ram 1500, Tubular Upper Control Arm/Delta Joint Kit at Sexton Offroad in Salt Lake City & Park City, Utah

Take the performance of your 2009-UP Dodge RAM 1500 to new levels with the ICON Vehicle Dynamics Delta Joint tubular upper control arm kit. All ICON tubular upper control arms are constructed from CNC bent 1026 DOM steel tubing and then powder coated to a semi-gloss black finish for maximum strength and corrosion resistance. ICON upper control arms are engineered with built-in caster correction for optimal alignment specifications and confidence inspiring handling. A main benefit of ICON upper control arms is the potential for increased wheel travel when paired with our 2.5 series coilovers, this translates into superior performance and ride quality for your 2009-UP Dodge RAM 1500.

These upper control arms feature ICON's patented Delta Joint. The Delta Joint is a heavy duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greasable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

Features | Specification:

• ICON Delta Joint
• 1026 DOM Steel Construction
• CNC Bent Tubing
• Serviceable Dual Stage Bushings
• CNC Machined Bushing Housings and Sleeves
• Built-In Caster Correction
• Black Semi-Gloss Powder Coat Finish

Note(s):

• OEM Wheels & Tires Fitment: Yes
• Recommended Aftermarket Wheels (2009-2018): ICON Alloys - 17x8.5 with 4.75" Backspace / 0mm Offset
• Recommended Aftermarket Wheels (2019-UP): ICON Alloys - 18x9" w/ 5.00" Backspace / 0mm Offset
• Recommended Aftermarket Wheels (2019-UP): ICON Alloys - 20x9" w/ 5.00" Backspace / 0mm Offset
• Recommended Aftermarket Tires (2009-2018): 33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
• Recommended Aftermarket Tires (2019-UP): 35" x 12.50" (Fender trimming and modifications will be required.)
• Not compatible with models equipped with OE air suspension
• Not compatible with 2021-UP Ram 1500 TRX trims
• Also compatible with 2019-2022 Ram 1500 Classic models

Upgrade your 4x4 with quality parts and accessories from Sexton Offroad. Visit us for installation at our Salt Lake City or Park City, Utah locations. Plus, enjoy free shipping on thousands of products nationwide!

This Item Fits:

• Ram 1500 Big Horn 2011 - 2018
• Ram 1500 Laramie 2011 - 2018
• Ram 1500 Laramie Longhorn 2011 - 2018
• Ram 1500 Outdoorsman 2011 - 2018
• Ram 1500 SLT 2011 - 2018
• Ram 1500 ST 2011 - 2018
• Ram 1500 Sport 2011 - 2018
• Ram 1500 Tradesman 2011 - 2018
• Ram 1500 SXT 2011
• Ram 1500 SXT 2013
• Ram 1500 SXT 2015 - 2018
• Ram 1500 Express 2012 - 2018
• Ram 1500 Tradesman HD 2012
• Ram 1500 HFE 2013 - 2018
• Ram 1500 R/T 2013
• Ram 1500 Lone Star 2014 - 2018
• Ram 1500 Special Service 2014 - 2018
• Ram 1500 Laramie Limited 2014
• Ram 1500 Laramie Limited 2018
• Ram 1500 Big Horn 2019 - 2022
• Ram 1500 HFE 2019 - 2022
• Ram 1500 Laramie 2019 - 2022
• Ram 1500 Limited 2019 - 2022
• Ram 1500 Lone Star 2019 - 2022
• Ram 1500 Rebel 2019 - 2022
• Ram 1500 SLT 2019 - 2022
• Ram 1500 Sport 2019 - 2022
• Ram 1500 Tradesman 2019 - 2022
• Ram 1500 Laramie Longhorn 2019 - 2021
• Ram 1500 ST 2019 - 2021
• Ram 1500 SXT 2019
• Ram 1500 Hemi Sport 2020 - 2022
• Ram 1500 Laramie Sport 2020 - 2021
• Ram 1500 Special Service 2020 - 2021
• Ram 1500 Limited Longhorn 2021 - 2022
• Ram 1500 Longhorn 2021
• Ram 1500 Classic Express 2019 - 2022
• Ram 1500 Classic SLT 2019 - 2022
• Ram 1500 Classic Special Service 2019 - 2022
• Ram 1500 Classic Tradesman 2019 - 2022
• Ram 1500 Classic Warlock 2019 - 2022
• Ram 1500 Classic ST 2019 - 2020
• Ram 1500 Classic Big Horn 2019
• Ram 1500 Classic Laramie 2019
• Ram 1500 Classic Lone Star 2019
• Ram 1500 Classic SXT Plus 2019
• Ram 1500 Classic Night Edition 2021
• Dodge Ram 1500 Laramie 2009 - 2010
• Dodge Ram 1500 SLT 2009 - 2010
• Dodge Ram 1500 ST 2009 - 2010
• Dodge Ram 1500 Sport 2009 - 2010
• Dodge Ram 1500 TRX 2009 - 2010
• Dodge Ram 1500 TRX4 2009 - 2010
